| Engine |
|---|
| Brand |
Scania |
| Type |
DC09 |
| Stage |
Stage IV Final |
| Power |
232 kW / 315 hp |
| Undercarriage |
|---|
| Drive line |
Hydrostatic drive systeem |
| Tracks |
Oscillating with D4 chain |
| Track Rollers |
Lifetime lubricated |
| Track Pads |
800 mm - triple grouser |
| Control |
by means of electric joysticks - high / low |
| Travel speed |
0 - 8.000 m/hours |
| Discharging |
|---|
| Hopper capacity |
8 to 12m2 |
| Hopper |
Hydraulically liftable |
| Discharge system |
180° swing conveyor in front |
| Discharge height |
500 - 3.500 mm |
| Conveyer control |
by means of electric joystick - stepless adjustable |
| Dimensions |
|---|
| Length |
9.000 m |
| Width |
3.000 m |
| Height |
3.150 m |
| Weight |
18 tonne |
Options
- Engine speed 1.600 rpm
- Temperature controlled fan, self cleaning
- Automatic greasing system
