Agro Trenching: EGS / BSS 3000

Engine
Brand Scania
Type DC09
Stage  Stage IV Final
Power 232 kW / 315 hp

Undercarriage
Drive line Hydrostatic drive systeem - GPS prepared
Tracks  Oscillating with D4 chain
Track Rollers Lifetime lubricated
Track Pads 800 mm - triple grouser
Control by means of electric joysticks - high / low - load control
Travel speed 0 - 5.000 m/hours

Trenching System
Drive line Hydrostatic drive system - GPS or laser prepared
Hydraulic motors 2x high torque motors - 1000 cc
Final drive  Lifetime seals
Trench width 175 - 500 mm
Depth range 1.700 mm
Max. trench depth 2.400 mm
Control by means of electric joystick - stepless adjustable
Digging speed  0 - 5.000 m/s

Dimensions
Length 12.000 m
Width 3.000 m
Height 3.150 m
Weight 20 tonne


Options
- Engine speed 1.600 rpm
- Mechanical driven digging chain
- Parallel linkage system (EGS 3000)
- Travel speed up to 8.000 m/hour
- Temperature controlled fan, self cleaning
- Automatic greasing system
- Storage platform for pipe coils
