| Engine |
| Brand |
Scania |
| Type |
DC13 |
| Stage |
Stage IV Final |
| Power |
405 kW / 550 hp |
| Undercarriage |
| Drive line |
Hydrostatic drive systeem - GPS prepared |
| Tracks |
Oscillating with D5B chain |
| Track Rollers |
Lifetime lubricated |
| Track Pads |
800 mm - triple grouser |
| Control |
by means of electric joysticks - high / low - load control |
| Running Speed |
0 - 5.000 m/hours |
| Trenching System |
| Drive line |
Hydrostatic drive system - GPS or laser prepared |
| Hydraulic motors |
2x high torque motors - 2000 cc |
| Final drive |
Lifetime seals |
| Trench width |
175 - 500 mm |
| Depth range |
2.300 mm |
| Max. trench depth |
3.000 mm (5.000 mm deep trenching) |
| Control |
by means of electric joystick - stepless adjustable |
| Travel speed |
0 - 5.000 m/s |
| Dimensions |
| Length |
12.000 m |
| Width |
3.000 m |
| Height |
3.150 m |
| Weight |
30 tonne |
Options
- Engine speed 1.600 rpm
- Hydraulic quick connect coupling
- Vertical digging boom for deep trenching
- Travel speed up to 8.000 m/hour
- Temperature controlled fan, self cleaning
- Automatic greasing system
- Storage platform for pipe coils
